5A 2.2mm pitch 7pin male female right angle pogo pin magnetic connector.
The 7pin magnetic connector is a compact, medium-current interconnect solution designed for secure and detachable connections in electronics.
Key Specifications:
Continuous Working Current: 5A
Voltage Rating: 12V
Pitch: 2.2mm (compact spacing for dense PCB layouts).
Pin Number: 7-pin (male + female pair).
Right-Angle Design: Saves space in tight enclosures.
Pogo Pin Contacts: Spring-loaded for reliable, low-resistance connections.
Gender: Male and female versions available (mating pair).
Magnetic attraction force between the male and female docking interfaces of 7pin right angle magneti connector is >450 grams (g),, which is critical for stable connections in high-vibration or portable applications. The male female magnetic connector is use N52-grade neodymium magnets, N52 is the highest grade of commercially available neodymium magnets,it is high-performance permanent.
Applications:
Modular Electronics: Quick-release PCBs, test fixtures.
Consumer Devices: Magnetic charging/data ports (e.g., wearables, IoT).
Medical/Industrial Equipment: Reusable connectors for diagnostics.
Drones & Robotics: Detachable power/signal connections,ect.
Advantages:
✅ Space-Saving: Right-angle + 2.2mm pitch suits small devices.
✅ Durability: Pogo pins withstand repeated mating cycles,test life more than 5000 times minium
✅ User-Friendly: Magnetic self-alignment simplifies connections.
✅ Modularity: Easy replacement/upgrades.
7pin magnetic connectors parameter:
| Name | 7Pin Magnetic connectors |
| Pin | 7pin or customized |
| Pitch | 2.20mm |
| Type | Right angle |
| Pogo pin | Brass |
| Housing | Black HTN+30%GF UL94 V-0 |
| Magnet | Neodymium iron boron |
| Magnet grade | N52(As requirement) |
| Magetic force | 450G |
| Spring force | 80g±20g,at 1.0mm working storke. |
| Mechanical life | 5000 cycle Min.. |
| Current | 5A |
| Voltage | DC 12V |
| Contact resistance | 50mΩ Max (PIN). |
| High voltage test | AC1000 V0.5mA 3SEC / DC 1000V 0.5mA 3 SEC. |
| Salt spray test | 48H |
| Certification | ROHS or REACH compliant product |
| Test | 100% open and short test |
7pin male right angle magnetic connectors:
7pin female right angle magnetic connectors:
Recommended pcb layout:
Layout tolerance:±0.05mm
Why do customers choose US?
1.Customization & Flexibility
2.Fast Samples = Faster Time-to-Market
3.Every connector undergoes rigorous quality checks
Incoming Material Inspection
In-Process Quality Checks
100% Final Testing
Traceability & Compliance
4.Customer-Focused QC Flexibility
5.Real-Time QC Collaboration
Magnetic connectors application:
We can provide design service
Payment method: T/T,PayPal,OCBC
Sample Lead Time: Inventory sample 2-3Working day/customized sample 5-7Working day
Production Lead Time:10-15Working day
Made For: America,Europe,Asia,South African
Trade Term: EXW
Service: High quality with reasonable price, OEM service, any special size, color, designs are acceptable
Pakaging & shipping
Any question, please send to union@upetech.net
